Model Number : UL20041 COMPUTER WIRE

Accepted Delivery Terms : FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DDP, DDU, Express Delivery

Payment Terms : T/T, L/C

Certification : TUV Certification, UL Certification, CB Certification, CE Certification

MOQ : 100 meters

Brand Name : Guoning

Contact Now

UL20041 COMPUTER WIRE

Rated temperature:105℃
Insulation provide high temperature resistance and enhanced electrical properties
Uniform insulation thickness to ensure easy stripping and cutting
For general purpose internal wiring of appliance
High quality Solid or stranded ,tinned or bare copper conductor

Product Introduction

Details

Applications

For general purpose internal wiring of appliance

Construction

Technical characteristics

Rated voltage:30V
Rated temperature:105℃
PVC,XL-PVC,XLPE,SR-PVC insulation, PVC jacket, comply with RoHS environmental standard
Passes ULVW-1&CSAFTI flame test
Standard:UL758 UL1581

UL 20041
CONDUCTOR				INSULATION		SHIELD	DRAIN	BRAID	JACKET		MAX. COND. RESISTANCE (Ω/km,20℃,DC)
AWG	CONSTRUCTION (№./mm)	DIA (mm)	NUMBER OF CORES	THICKNESS (mm)	O.D. (mm)	CONSTRUCTION (№./mm)	CONSTRUCTION (№./mm)	CONSTRUCTION (№./mm)	THICKNESS (mm)	O.D. (mm)	MAX. COND. RESISTANCE (Ω/km,20℃,DC)
30	7/0.10	0.3	10P	0.15	0.6	AI-mylar	7/0.10	16/8/0.10	0.65	5.4	381
			15P	0.15	0.6	AI-mylar		24/4/0.10	0.65	6.2
			18P	0.15	0.6	AI-mylar		24/4/0.10	0.69	6.7
			19P	0.15	0.6	AI-mylar		24/4/0.10	0.72	6.9
			25P	0.15	0.6	AI-mylar		24/8/0.10	0.75	7.7
28	7/0.127	0.38	10P	0.15	0.7	AI-mylar	7/0.127	16/6/0.10	0.65	6	239 150
			15P	0.15	0.7	AI-mylar		24/5/0.10	0.73	7.1
			18P	0.15	0.7	AI-mylar		24/8/0.10	0.74	7.6
			19P	0.15	0.7	AI-mylar		24/8/0.10	0.76	7.8
			25P	0.15	0.7	AI-mylar		24/9/0.10	0.84	8.8
26	7/0.16	0.48	3P	0.15	0.8	AI-mylar	7/0.16	16/6/0.10	0.64	4.4
			6P	0.15	0.8	AI-mylar		24/6/0.10	0.64	5.5
			9P	0.15	0.8	AI-mylar		24/7/0.10	0.68	6.4
NOTE:The product's detailed description please refer to the specification for approval

Product structure
